DCR021205P-U Batteries & Power Supplies by Texas Instruments


Status: Unknown
Series: -
RoHS: Unknown
View Datasheet Manufacturer Site View Pricing & Stock

The DCR02 family is a series of high-efficiency, inputisolated, output-regulated DC/DC converters. In addition to 2−W nominal, galvanically-isolated output power capability, this range of converters offers very low output noise and high accuracy. The DCR02 family is implemented in standard molded device packaging, providing standard JEDEC outlines suitable for high-volume assembly. The DCR02 family is manufactured using the same technology as standard device packages, thereby achieving very high reliability. WARNING: This product has operational isolation and is intended for signal isolation only. It must not be used as a part of a safety isolation circuit requiring reinforced isolation. See definitions in Isolation.
Distributor Price Stock
Logo for Texas Instruments Texas Instruments US$15.95
Buy Now
View Full Pricing & Stock Comparison


No. of Outputs 1 Output, 1Outputs
Output Power Max 2W
Output Voltage - Output 1 5V
Output Current - Output 1 400mA
Output Voltage - Output 2 -
Output Current - Output 2 -
Output Voltage - Output 3 -
Output Current - Output 3 -
Product Range -
Input Voltage DC Min -
Input Voltage DC Max 12V
DC / DC Converter Output Type Fixed
DC / DC Converter Type Surface Mount DIP
DC / DC Converter Mounting Surface Mount Device
Width 7.11mm
Height 4.95mm
Depth 23.37mm
SVHC No SVHC (27-Jun-2018)
Accuracy % 0.5%
Frequency 400kHz
No. of Pins 10Pins
Operating Temperature Max 70°C
Operating Temperature Min -40°C
Operating Temperature Range -40°C to +70°C
Output Voltage Max 5V
Supply Voltage Max 13.2V
Supply Voltage Min 10.8V
Voltage Regulator Type Isolated Converter
