SN74LS164N Logic by Texas Instruments
IC 74LS 74LS164 DIP14 7V
| Status: | Unknown |
|---|---|
| Series: | - |
| RoHS: | Unknown |
Where to Buy
Prices starting from US$0.30
| Distributor | Stock | ||
|---|---|---|---|
|
RS
from US$0.67
|
40
in stock
|
Buy Now |
|
Texas Instruments
from US$0.30
|
101,796
in stock
|
Buy Now |
|
Transfer Multisort Elektronik
from US$0.43
|
948
in stock
|
Buy Now |
|
Newark Electronics
from US$0.90
|
930
in stock
|
Buy Now |
|
element14
from US$0.70
|
930
in stock
|
Buy Now |
|
Farnell
from US$0.75
|
926
in stock
|
Buy Now |
|
Chip One Stop
from US$0.36
|
96
in stock
|
Buy Now |
Specifications
| Logic Family / Base Number | 74LS164 |
|---|---|
| Shift Register Function | Serial to Parallel |
| No. of Elements | 1 Element, 1Elements |
| No. of Bits Per Element | 8bit |
| Logic Case Style | DIP |
| No. of Pins | 14Pins |
| Supply Voltage Min | 4.75V |
| Supply Voltage Max | 5.25V |
| IC Output Type | Standard |
| Logic IC Family | 74LS |
| Logic IC Base Number | 74164, 74164 |
| Operating Temperature Min | 0°C |
| Operating Temperature Max | 70°C |
| Product Range | - |
| Automotive Qualification Standard | - |
| RoHS Phthalates Compliant | Yes |
| MSL | - |
| SVHC | No SVHC (27-Jun-2018) |
| Base Number | 74 |
| Device Marking | SN74LS164N |
| Frequency | 36MHz |
| IC Generic Number | 74LS164 |
| IC Temperature Range | Commercial |
| Input Current Max | 100µA |
| Logic Function Number | 74164 |
| Logic IC Function | 8bit Serial-In/Parallel-Out Shift Register |
| Logic Type | Shift Register |
| Operating Temperature Range | 0°C to +70°C |
| Power Dissipation Ptot Max | 10mW |
| Supply Voltage | 7V |
| Supply Voltage Range | 4.75V to 5.25V |
| Termination Type | Through Hole |
Alternative Descriptions
| Serial-in shift registers | Texas Instruments |
| IC: digital | Transfer Multisort Elektronik |
| Ic, 74Ls, 74Ls164, Dip14, 7V | Newark Electronics |
| IC, 74LS, 74LS164, DIP14, 7V | element14 |
| 8-bit SIPO shift register,SN74LS164N | RS |
